Max. Vacuum power
850 mbar (85 kPa, 638mmHg) ±10%
Vacuum regulation
linear
Vacuum range regulation
> 22 liters per minute with free air ±10%
Max. running time with the maximum current-load
Approximately 45 minutes ±10%
Approximate maximum noise energy
65 dBA
Accuracy of the analogue gauge
±5%
Accuracy of the battery power monitor
±5%
Running/Charging
12 ÷ 15 Vdc (direct current)
Max. current load
70W (max. current 6A)
Battery
sealed acid type, capacity 12V / 3,2 Ah
Max. time for charging
15 hours
Main safety
Internal not accessible to the user
Max. dimensions
320mm (width) x 100mm (depth) x 250mm (height)
12.6 in (width) x 3.94 in (depth) x 9.84 in (height)
Weight
3.5 Kg Max. complette with all accessories
Tolerance on all values
±5%
Max. Vacuum power
800 mbar (80 kPa, 600mmHg) ±10%
Vacuum regulation
linear with integrated mechanical regulator
Max. flow rate
33 LPM (liters per minute) at open flow ±10%
Vacuum range regulation
30 ÷ 800 mbar (3 ÷ 80 kPa)
Max. running time with the maximum current-load
60 minutes ±10% run time
Approximate maximum noise energy
70 dB
Accuracy of the analogue gauge
±5%
Accuracy of the battery power monitor
±5%
Running/Charging
11 ÷ 25 Vdc (direct current)
Max. current load
80W (max. current 8A)
Battery
Extractable, LiPo, 11.1V - 5Ah
Max. time for charging
10-15 hours consecutive
Main safety
Internal not accessible to operator
Max. dimensions
360mm (l) x 244mm (h) x 195mm (p)
Weight
2.6 Kg Max. complette with all accessories, 780gr wall bracket
Tolerance on all values
±5%
Max. Vacuum power
850 mbar (85 kPa, 637.5mmHg) ±10%
Vacuum regulation
linear with integrated mechanical regulator
Max. flow rate
24 LPM (liters per minute) at open flow ±10%
Vacuum range regulation
30 ÷ 850 mbar (3 ÷ 85 kPa)
Max. running time with the maximum current-load
>70 minutes ±10% run time
Approximate maximum noise energy
70 dBA
Accuracy of the analogue gauge
±5%
Accuracy of the battery power monitor
±5%
Running/Charging
11 ÷ 25 Vdc (direct current)
Max. current load
80W (max. current 8A)
Battery
Extractable, LiPo, 11.1V - 5Ah
Max. time for charging
10-15 hours consecutive
Main safety
Internal not accessible to operator
Max. dimensions
290mm (l) x 240mm (h) x 95mm (d)
Weight
1.8 Kg Max. complette with all accessories
Tolerance on all values
±5%
